What kind of fuel systems is this pump designed for?

This Aeromotive Pro-Series fuel pump is designed for high-horsepower EFI (Electronic Fuel Injection) and carbureted systems. It is not compatible with diesel fuel.

Can this fuel pump be installed inside the fuel tank?

Yes, this fuel pump is fully submersible and can be installed inside the fuel tank. This is a common practice for custom builds to keep the engine bay cleaner and ensure consistent fuel supply.

What are the inlet and outlet port sizes on this pump?

The pump features ORB-12 inlet and outlet ports. It also includes two ORB-12 to AN-12 male adapter fittings to help connect your fuel lines.

Questions? Call Us:631-982-0042

M-F 8AM-4PM ET

Trusted Since 1957

Est. 1957

Aeromotive Pro-Series Fuel Pump - EFI or Carbureted Applications

1 / 4

Specifications

Brand: Aeromotive
Part #: 11102
UPC: 684980000344

Aeromotive Pro-Series Fuel Pump - EFI or Carbureted Applications

Name: Aeromotive Pro-Series Fuel Pump - EFI or Carbureted Applications
Brand: Aeromotive
SKU: aeromotive-aeromotive-pro-series-fuel-pump-efi-or-carbureted-applications-t14-4339864
Price: 1132.13 USD
Availability: InStock

$1132.13

Only 5 left in stock

This Aeromotive Pro-Series fuel pump handles extreme horsepower for racing engines. Features a dual chamber design and ORB-12 ports.

Key Features

Supports up to 2600 HP on carbureted engines
Supports up to 2200 HP on fuel-injected engines
Dual chamber pump design
ORB-12 inlet and outlet ports
Includes two ORB-12 to AN-12 male adapter fittings
Fully submersible for in-tank installation
