BMW 3 Series (E90 - E93) Service Manual (2006-2011)

This BMW 3 Series repair manual contains in-depth maintenance, service and repair information for BMW 3 Series models built on the E90, E91, E92 or E93 platforms from 2006 to 2011. The aim throughout has been simplicity and clarity, with practical explanations, step-by-step procedures and accurate specifications. Whether you're a professional or a do-it-yourself BMW owner, this manual helps you understand, care for and repair your BMW. The do-it-yourself BMW owner will find this manual indispensable as a source of detailed maintenance and repair information. Even if you have no intention of working on your vehicle, you will find that reading and owning this manual makes it possible to discuss repairs more intelligently with a professional technician.





Technical features:

• Maintenance procedures from changing the ATF to replacing
  the cabin microfilter. This manual tells you what to do and
  how and when to do it

• Step-by-step variable camshaft timing (VANOS) service
  for N51, N52 and N54 engines

• Cylinder head cover gasket and crankshaft seal replacement

• Cooling system and radiator service

• Fuel injection and ignition system diagrams and explanations

• Information about advanced technical features such as
  Valvetronic, xDrive, twin turbo boost
  and DSC (dynamic stability control)

• Suspension repair procedures

• Brakes, steering and ABS troubleshooting and repair

• Heating and air-conditioning repair,
  including A/C component replacement

• Body and hood repairs and adjustments

• Electrical system service, with an easy-to-use illustrated
  component locator section

• Comprehensive wiring schematics, including fuses and grounds

• BMW OBD II diagnostic trouble codes, SAE-defined
  OBD II P-codes, as well as basic scan tool operation

• BMW factory tolerances, wear limits, adjustments
  and tightening torques



Normally aspirated models
(6-cylinder 3.0 engines):

• 325i, 330i, N52 engine (rear-wheel drive)

• 328i, N52KP, N51 engine (rear-wheel drive)

• 325xi, 330xi N52 engine (all-wheel drive or xDrive)

• 328xi N52KP, N51 engine (all-wheel drive or xDrive)

Twin turbo-charged models
(6-cylinder 3.0 engines)

• 335i N54 engine (rear-wheel drive)

• 335xi N54 engine (all-wheel drive or xDrive)

• Transmissions covered
  (remove, install, external service)

• Getrag GS6-17BG manual

• ZF GS6-37BZ(X) manual

• ZF GS6-53DZ(X) manual

• GM GA6L45R automatic

• ZF GA6HP19Z automatic
