Volkswagen Jetta, Golf, GTI & Cabrio Service Manual (1993-2002)

Applications: Jetta, Golf, GTI: 1993-1999 Cabrio: 1995-2002





Technical highlights:

• Covers Volkswagen A3 models with "1H" or "1E" at position number 7
  and 8 of 17-digit Vehicle ID Number (VIN).

• Includes Golf and Jetta Cl, GL, LE, GLS, GLX, GTI, City, Wolfsburg,
  Trek, K2 and Cabrio Highline editions.

• Tune-up and maintenance procedures, including resetting
  the Service Reminder Indicator (SRI).

• Engine and cylinder head service and reconditioning,
  including timing belt (4-cylinder) and timing chain (6-cylinder) repair.

• Explanation of Bosch Motronic, Mono-Motronic, Diesel Fuel Injection
  and Turbo Direct Injection (TDI) systems.

• Emission control tests, repairs, and adjustments,
  including Exhaust Gas Recirculation (EGR) and Secondary Air Injection system.

• Drivetrain maintenance, troubleshooting, adjustment and repair,
  including hydraulic clutch, gearshift linkage, and axles.

• Suspension component replacement, including front struts,
  rear shocks, rear coil springs, and wheel bearing/hub units.

• Disk/drum brake repair and troubleshooting,
  including anti-lock brakes (ABS) and traction control (EDL)

• Heating and air conditioning repair, including A/C blower motor replacement
  and specifications for R134a refrigerant.

• Body adjustment and repairs, including sunroof adjustments
  and manual/power Cabrio top.

• Wiring schematics, including fuse/relay locations
  and a general explanation of electrical circuitry.

• Volkswagen OBD II diagnostic trouble codes, SAE-defined OBD II P-codes,
  as well as control module coding.
