Does this radiator include all the necessary hardware for installation?

This radiator is designed as a direct fit and accepts all original attaching OEM components, including mounting brackets, the AC condenser, and fan shroud. You can reuse your factory hoses and hardware.

What makes CSF's B-Tube Technology different from standard radiator tubes?

CSF's B-tubes are specially shaped to increase the heat transfer surface area by approximately 15% compared to regular oval tubes. This design allows for more efficient cooling by creating a 'dual liquid laminar flow' within the same space.

Will this radiator work with my factory cooling fan and shroud?

Yes, this CSF radiator is designed to accept all original attaching OEM components, including the fan shroud. You should be able to transfer your factory fan and shroud directly onto the new radiator.

2013-2020, 2022-2025 Subaru BRZ Radiator | CSF 7050

Name: CSF 13-16 Scion FR-S / 13-20 Toyota 86 / 22+ Toyota GR86 / 2013+ Subaru BRZ Radiator
Brand: CSF
Price: 325.00 USD
Availability: InStock

CSF 13-16 Scion FR-S / 13-20 Toyota 86 / 22+ Toyota GR86 / 2013+ Subaru BRZ Radiator

$325.00

In Stock

Fits 2013-2020, 2022-2025 Subaru BRZ. CSF all-aluminum radiator for improved engine cooling.

Key Features

Fits 2013-2016 Scion FR-S, 2013-2020 and 2022-2025 Subaru BRZ, 2017-2020 Toyota 86, and 2022-2025 Toyota GR86.
Features a 2-row, 42mm core with CSF's exclusive B-Tube Technology for increased heat transfer surface area.
Utilizes ultra-efficient, multi-louvered fins that are precisely aligned to maximize airflow and heat rejection.
Designed as a direct fit, requiring no modifications for installation and accepting all original attaching components.
Includes CNC-machined brackets and fittings for durability and a precise fit.
Features CNC-machined inlet and outlet connections to match OE specifications for easy hose reuse.

Secure CheckoutFast Shipping631-982-0042

Will this fit your vehicle?

Product Details

If you're pushing your 2013-2020, 2022-2025 Subaru BRZ, Scion FR-S, or Toyota 86/GR86 hard, whether on the street or the track, keeping your engine cool is critical. This all-aluminum radiator from CSF is built to handle the extra heat generated by spirited driving or performance modifications.

CSF uses a unique 2-row, 42mm core with their B-Tube Technology. Unlike standard oval tubes, these specially shaped tubes increase the heat transfer surface area by about 15%, allowing for more efficient cooling. The radiator also features multi-louvered fins that are precisely aligned to maximize airflow through the core, further improving heat dissipation. This radiator is designed as a direct fit, meaning it bolts right into place using your vehicle's original mounting brackets and connects to your factory hoses, making installation straightforward.

This radiator is a solid option for anyone looking to upgrade their cooling system. It's well-built with CNC-machined brackets and fittings for durability and a precise fit, ensuring it integrates smoothly with your existing components like the AC condenser and fan shroud.
