Fabtech 11-16 Ford F250/350/450/550 4WD 6in C/O Conv Sys Dlss 4.0 C/O& Hoops Only

Fabtech is known for building robust suspension components for trucks, and their 6" Dirt Logic 4.0 Coilover Conversion System for your 2011-2016 Ford F-250 Super Duty is a prime example. This system is designed to replace your factory coil spring buckets with stout, gusseted 1 3/4 inch tubing, providing a solid foundation for serious suspension upgrades. It's built to work with Fabtech's Dirt Logic 4.0 Coilover Shocks, offering maximum front suspension damping for your Super Duty.

The upper coilover mounts are constructed from 1.75 inch diameter DOM tubing, spanning a wide section of the frame to properly distribute impact loads. These replace the factory coil spring mounts entirely. Down below, 1/4 inch thick steel lower mounts attach directly to the axle housing, creating strong anchor points for the Dirt Logic 4.0 Stainless Steel Coilover shocks, which feature piggyback reservoirs. This setup is also compatible with Fabtech's Radius Arm and 4 Link systems, giving you flexibility in your build.

This kit includes the coilover hoops, lower mounts, and all necessary hardware to get the job done. For an even more complete suspension upgrade, consider adding Fabtech's hydraulic bump stops. This system is a significant step up for those looking to maximize their Super Duty's front suspension performance.
