Fabtech 11-16 Ford F250 4WD 6in 4Link Sys w/Dlss 4.0 C/O& Rr Dlss

The upper coilover mounts in this Fabtech 6-inch lift system are built from 1.75-inch diameter DOM tubing. This robust construction replaces the factory coil spring mounts and spreads the load across a wide frame section, ensuring proper impact distribution for your 2008-2016 Ford F-250 Super Duty. This kit is designed to give your truck improved front suspension damping using Dirt Logic 4.0 Stainless Steel Coilover Conversion shocks. These shocks feature piggyback reservoirs for enhanced performance and are paired with 1/4-inch thick steel lower mounts that attach directly to the axle housing for solid connection points.

Beyond the front suspension, this kit includes a bolt-on 4-Link System that significantly boosts articulation and wheel travel. The 2-inch diameter, heavy-wall links use 1-inch race-style Uniballs for superior strength, and 1/4-inch steel brackets attach the links to the frame without requiring any cutting or welding. You'll also find billet sway bar end links with heim ends, quad-layer limiting straps, and rear 2.25-inch Dirt Logic Stainless Steel shocks to complete the package. This comprehensive system also comes with Sway Bar Drops, a Trac Bar relocation bracket, a Pitman Arm, and a U-Bolt kit, making it a complete solution for a 6-inch lift.
