Fabtech 11-16 Ford F250 4WD 6in Rad Arm Sys w/Dlss 4.0 C/O& Rr Dlss

If you're looking to give your 2008-2016 Ford F-250 Super Duty a significant lift and improved suspension performance, this Fabtech Radius Arm System is a solid choice. This kit is designed to provide maximum front suspension damping, especially when paired with the included Dirt Logic 4.0 Stainless Steel Coilover Conversion system. It's a comprehensive package aimed at enhancing both the capability and ride quality of your truck for off-road use.

The heart of the front suspension upgrade lies in the Dirt Logic 4.0 Stainless Steel Coilover shocks. These are mounted using robust upper brackets made from 1.75-inch diameter DOM tubing, which spread the load across a wide frame area for better impact distribution. The lower mounts are constructed from thick 1/4-inch steel and attach directly to the axle housing, ensuring a strong connection point for the coilovers. The system also includes billet sway bar end links with heim ends and quad-layer limiting straps to control suspension travel. For the rear, you get 2.25-inch Dirt Logic Stainless Steel shocks. The kit features Fabtech's patented Radius Arms, which are built with a full tubular structure reinforced by dimple-die side plates. An adjustable alignment cam at the axle allows for precise caster adjustment, which is crucial after a lift. The kit includes replacement front coil springs to achieve the 6-inch lift, along with a Trac Bar relocation bracket, Pitman Arm, Sway Bar drops, and a rear Block & U-bolt kit to complete the installation.

This kit is designed for a 6-inch lift and includes everything needed to get your F-250 Super Duty up and ready for tougher terrain. It's a well-built system that addresses the key suspension components for a substantial lift and improved damping performance.
