Fabtech 11-16 Ford F250 4WD w/Factory Overload 8in 4Link Sys w/4.0 R/R & 2.25

Starting with the massive 4-inch diameter aluminum remote reservoir on the Dirt Logan 4.0 Coilover Conversion is a clear indicator of the performance this Fabtech 4-Link system brings to your 2011-2018 Ford F-250 Super Duty. This system replaces the factory Radius Arm setup with a robust 4-Link design, which is a significant upgrade for both on-road comfort and off-road capability. The improved geometry means less caster change as the suspension moves, leading to more stable handling on the highway, while the increased articulation allows you to tackle tougher terrain with greater confidence.

Fabtech has engineered this kit with heavy-duty, 2-inch diameter, thick-wall links that use race-style 1-inch Uniballs for exceptional strength. The 1/4-inch steel brackets bolt directly to the frame, meaning no cutting or welding is required for installation, making it a straightforward bolt-on conversion. The Dirt Logan 4.0 Coilovers are designed to fit in place of the factory coil springs without needing to remove the coil spring buckets, and their large diameter provides outstanding damping for a quality ride. This system also includes sway bar drops, a trac bar relocation bracket, a Pitman arm, and a U-bolt kit to ensure you have all the necessary components for a complete conversion.

With over a decade of proven performance, including use in military applications, this Fabtech 4-Link system is built for reliability. It comes with a 5-year, 60,000-mile powertrain warranty, giving you peace of mind with your investment. This kit is designed to work with factory overloads and is compatible with both the F-250 and F-350 Super Duty models from the specified years.
