What is the primary benefit of converting to a 4-Link suspension system?

Converting to a 4-Link system offers improved on-road performance by reducing caster change throughout the suspension travel. Off-road, it provides greater articulation and wheel travel compared to the factory Radius Arm setup, allowing for better traversal of rugged terrain.

Does this lift kit require welding or cutting for installation?

No, this Fabtech 4-Link system is designed as a direct bolt-on replacement. The included 1/4-inch steel brackets secure the 4 Links to the frame without the need for cutting or welding.

What is included with the Dirt Logan 4.0 Coilover Conversion?

The Dirt Logan 4.0 Coilover Conversion includes massive 4-inch diameter aluminum remote reservoir coilovers. These are designed to mount horizontally above the coilover, allowing for full compression travel even with oversized tires, and provide outstanding damping capacity.

Fabtech 11-16 Ford F250 4WD w/o Factory Overload 8in 4Link Sys w/4.0 R/R & 2.25

1 / 2

Fabtech

Specifications

Brand: Fabtech
Part #: K2276DL

Fabtech

Fabtech 11-16 Ford F250 4WD w/o Factory Overload 8in 4Link Sys w/4.0 R/R & 2.25

Name: Fabtech 11-16 Ford F250 4WD w/o Factory Overload 8in 4Link Sys w/4.0 R/R & 2.25
Brand: Fabtech
Price: 6241.30 USD
Availability: InStock

$6241.30

Fits 2011-2018 Ford F-250 Super Duty. This 8" 4-Link lift system converts your front suspension for improved on-road and off-road performance.

Key Features

Fits 2011-2018 Ford F-250 Super Duty 4WD models without the factory overload spring.
Converts the front suspension from factory Radius Arms to an advanced 4-Link system.
Massive 4-inch diameter aluminum remote reservoir Dirt Logan 4.0 Coilovers offer superior damping for on-road comfort and off-road control.
The Dirt Logan 4.0 Coilovers bolt directly in place of the factory coil springs.
Heavy-wall 2-inch diameter links feature race-style 1.25-inch Uniballs for increased strength.
1/4-inch thick steel brackets attach to the frame without requiring cutting or welding.

⚠️ CA WARNING: This product can expose you to chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm. Learn more

Secure CheckoutFast Shipping631-982-0042

Fits these vehicles

Ford F-250 Super Duty 2011-2018
Ford F-350 Super Duty 2017-2018

Product Details

Starting with the massive 4-inch diameter aluminum remote reservoir on the Dirt Logan 4.0 Coilover Conversion is a clear indicator of the performance this Fabtech 4-Link system brings to your 2011-2018 Ford F-250 Super Duty. This system replaces the factory Radius Arms with a robust 4-Link setup, designed to give you better on-road manners and significantly more articulation for tackling tough off-road terrain. The improved suspension geometry means less caster change as the suspension moves, which translates to a more stable feel when you're driving on pavement.

Fabtech has engineered this kit to be a direct bolt-on replacement, meaning no cutting or welding is required on the frame for installation. The heavy-wall 2-inch diameter links are fitted with race-style 1.25-inch Uniballs for exceptional strength, and the 1/4-inch steel brackets ensure a solid connection. The Dirt Logan 4.0 Coilovers are designed to fit in place of the factory coil springs without needing to remove the coil spring buckets, and their large diameter provides outstanding damping capacity for a comfortable ride and controlled handling, even with oversized tires. This system has a proven track record, with over 10 years of service in military applications, highlighting its durability and reliability.

Included in this comprehensive kit are Sway Bar Drops, a Trac Bar relocation bracket, a Pitman Arm, and a U-Bolt kit, ensuring you have the necessary components for a complete conversion. Fabtech also backs this system with a 5-year, 60,000-mile powertrain warranty, giving you added peace of mind with your investment.
