What is the benefit of using a Uniball instead of a factory ball joint?

The Uniball design eliminates the upper ball joint, allowing for increased wheel travel and a more direct road feel due to reduced flex. This is a key feature for improving off-road performance and suspension responsiveness.

Does this system require modifications to the factory spindle?

No, the included 17-4 stainless steel heat-treated Uniball pin is designed to fit directly into the factory ball joint taper without any modification to the spindle. This allows for an easier installation and the ability to return to stock if needed.

What is included in this suspension system?

This system includes heavy-duty Upper Control Arms with 1 inch Uniballs, Dirt Logic 2.5 Coilover shocks for the front, and Dirt Logic 2.25 shocks for the rear. It is designed to provide a mild lift and significantly upgrade your truck's suspension.

1 / 2

Specifications

Brand: Fabtech
Part #: K2245DL

Fabtech 15-20 Ford F150 4WD 2in Uniball UCA Sys w/Dl 2.5 & 2.25

Name: Fabtech 15-20 Ford F150 4WD 2in Uniball UCA Sys w/Dl 2.5 & 2.25
Brand: Fabtech
SKU: fabtech-fabtech-15-20-ford-f150-4wd-2in-uniball-uca-sys-w-dl-2-5-2-25-t14-588554G
Price: 3104.91 USD
Availability: BackOrder

$3104.91

On Backorder

Order now to reserve yours — we'll ship as soon as stock arrives. Full refund if we're unable to fulfill.

Fits 2015-2020 Ford F-150 4WD. This Uniball UCA system with Dirt Logic 2.5 Coilovers and rear 2.25 shocks offers increased wheel travel and improved road feel.

Key Features

Fits 2015-2020 Ford F-150 4WD.
Features a 1 inch ID Stainless American Uniball to replace the factory upper ball joint.
Constructed from .120 wall 4130 chromoly tubing with a 1.25 inch OD for reduced flex and improved road feel.
Includes Dirt Logic 2.5 Coilover shocks for up to 10 inches of wheel travel.
Comes with rear Dirt Logic 2.25 shocks for a complete front and rear suspension upgrade.
17-4 stainless steel heat-treated Uniball pin fits factory ball joint taper without modification.

⚠️ CA WARNING: This product can expose you to chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm. Learn more

No-fit, no charge. Wrong part? Send it back, free return label.

Secure CheckoutFast Shipping631-982-0042

About this part

Product Details

Starting with 1.25 inch OD, .120 wall thick chromoly tubing, this Upper Control Arm system from Fabtech is built with the same robust materials found on Trophy Trucks. It replaces the factory arms on your 2015-2020 Ford F-150 4WD, eliminating the upper ball joint in favor of a super strong 1 inch ID Stainless American Uniball. This design allows for a significant increase in wheel travel, especially when paired with the included Dirt Logic 2.5 Coilover shocks, giving you up to 10 inches of total wheel travel for a complete front suspension upgrade.

The chromoly tubing used in these arms is stiffer than stock, which helps reduce flex and provides a more direct connection to the road. Installation is straightforward because the 17-4 stainless steel heat-treated Uniball pin fits directly into the factory ball joint taper without needing to modify your spindle. This means you can easily return your truck to stock if needed. The system also includes rear Dirt Logic 2.25 shocks, which have been tuned to work with the front coilovers, greatly increasing your vehicle's off-road suspension performance and ride quality.

This system is designed to provide a mild lift height while significantly improving your truck's suspension strength and alignment capabilities. The .250 wall DOM bushing barrels and 17-4 stainless steel misalignments further contribute to the system's durability and performance.
