Fabtech 17-21 Ford F250/F350 4WD Diesel 8in Rad Arm Sys w/Coils & Dlss Shks

This Fabtech 8-inch Radius Arm Lift System is designed for your 2017-2020 Ford F-250 or F-350 Super Duty 4WD with a diesel engine. What you get in this kit includes heavy-duty tubular radius arms with adjustable alignment cams for caster adjustment, replacement front coil springs, a track bar relocation bracket, a Pitman arm, sway bar drops, and a rear block and U-bolt kit. It also comes with Dirt Logic 2.25 Stainless Steel shocks to help smooth out the ride.

Fabtech developed this system with a unique offset track bar system to address the sensitive steering box found in these late-model Super Duty trucks when lifting them 8 inches and fitting larger tires. This track bar is 4 inches longer than stock and offset to the driver's side, with a 1/4-inch thick steel mounting bracket. This design helps keep the track bar and draglink closer to parallel, reducing steering feedback and allowing for full lock steering with tires up to 15.50 inches wide on 5-inch backspace wheels. The radius arms themselves are built with a full tubular structure, reinforced with dimple die side plates for added strength.

This kit is a bolt-on installation, meaning no welding is required, making it a straightforward upgrade for your truck. It's backed by Fabtech's 5-year, 60,000-mile warranty, giving you peace of mind. This system is a solid option for significantly changing your truck's stance and improving its off-road performance.
