Specifications
- Brand
- Gates
- Part #
- G20400-2024
- Dimensions
- 7.0" x 2.5" x 2.5"
- UPC
- 00072053456363
- Package Length
- 7.0 in
- Package Width
- 2.5 in
- Package Height
- 2.5 in
- Package Weight
- 2.37 lb
- Interchange Part Numbers
- Parker 1XA78-24-20, Kurt Hydraulics CAT-20-24-W, Goodyear DG-CF-2024, Kurt Hydraulics CAT-20-24-JJ, Caterpillar 2P-1416, Aeroquip 4S24CT20, Caterpillar 5P-3140, N20-24FLC, 04031131, Goodyear 28185-2024, Aeroquip 6S24CT20, Weatherhead 57020SK24
Caterpillar Style O-Ring Flange (GlobalSpiral)
$131.12
In Stock
Key Features
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250˚F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
UNIVERSAL APPLICATION · MEASURE BEFORE ORDERING
- Length
- 7.0 in
Add your vehicle to track confirmations →
About this part
Product Details
GlobalSpiral couplings are specially engineered to provide superior performance for extreme high-pressure, high-impulse spiral-wire hydraulic hose applications. They can be used with all Gates MegaSys four- and six-spiral wire hose up to 6,000 psi. When used with 2-wire ferrules, GlobalSpiral couplings can also be crimped on Gates wire-braid hoses. The innovative, two-piece, no-skive design reduces assembly time, labor, fabrication errors and contamination of the fluid power system. MGS Couplings for use with MC4-20 Crimper Only.
Description
Caterpillar Style O-Ring Flange (GlobalSpiral)Specifications
- Brand
- Gates
- Manufacturer Part #
- G20400-2024
- Dimensions
- 7.0" x 2.5" x 2.5"
- UPC
- 00072053456363
- Package Length
- 7.0 in
- Package Width
- 2.5 in
- Package Height
- 2.5 in
- Package Weight
- 2.37 lb
- Interchange Part Numbers
- Parker 1XA78-24-20, Kurt Hydraulics CAT-20-24-W, Goodyear DG-CF-2024, Kurt Hydraulics CAT-20-24-JJ, Caterpillar 2P-1416, Aeroquip 4S24CT20, Caterpillar 5P-3140, N20-24FLC, 04031131, Goodyear 28185-2024, Aeroquip 6S24CT20, Weatherhead 57020SK24
