Gates

Code 62 O-Ring Flange Heavy (GlobalSpiral Plus)

$113.21

Only 3 left in stock

Key Features

  • “Bite-the-wire” crimp for improved coupling retention
  • Tested to an industry-leading 1,000,000 impulse cycles
  • +250 Deg. F temperature capability for longer assembly life
  • Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard

UNIVERSAL APPLICATION · MEASURE BEFORE ORDERING

Length
7.0 in
Add your vehicle to track confirmations →
Secure CheckoutFast Shipping631-982-0042
About this part

Product Details

GlobalSpiral couplings are specially engineered to provide superior performance for extreme high-pressure, high-impulse spiral-wire hydraulic hose applications. They can be used with all Gates MegaSys four- and six-spiral wire hose up to 6,000 psi. When used with 2-wire ferrules, GlobalSpiral couplings can also be crimped on Gates wire-braid hoses. The innovative, two-piece, no-skive design reduces assembly time, labor, fabrication errors and contamination of the fluid power system. Separate ferrules are required for 4-spiral hose and wire braid hose.

Description

Code 62 O-Ring Flange Heavy (GlobalSpiral Plus)

Specifications

Brand
Gates
Manufacturer Part #
G22350-2432
Dimensions
7.0" x 3.0" x 3.0"
UPC
00770075417583
Package Length
7.0 in
Package Width
3.0 in
Package Height
3.0 in
Package Weight
2.87 lb
Interchange Part Numbers
Aeroquip 1Z32FH24, Aeroquip 4S32FH24, 04031575, Aeroquip 1E32FH24, 1241-3224, 4041-3224, Weatherhead 4SP24WD32, Continental Belt SG-FH-2432, Parker 16A78-32-24, NAPA G22350-2432, Goodyear 28300-2432
