Genius5 6V & 12V 5-Amp Smart Battery Charger

Powerful, high-performing, energy-efficient, and compact charger. This is a 6-volt and 12-volt battery charger, battery maintainer, and battery desulfator rated at 5-amps for lead-acid automotive, marine, and deep-cycle batteries, including flooded, gel, AGM, and maintenance-free, plus lithium-ion batteries.









Features:

• Detects and charges dead batteries
  as low as zero volts

• Plugs into standard outlet and converts
  A/C power into safe D/C power for battery charging

• Charging modes:
  - 12 Volt Mode
     Used for wet cell, gel, enhanced flooded
     maintenance-free and calcium batteries
  - 12 Volt AGM Mode
     Used for AGM batteries
  - 12 Volt Lithium Mode
     Used for lithium-ion batteries
     (including lithium iron phosphate).
     Only for batteries with Battery Management Systems
  - 6 Volt Mode
     Used for wet cell, gel, enhanced
     flooded maintenance-free, and calcium batteries
  - 12 Volt Repair Mode
     Used to repair old, idle, damaged,
     stratified, or sulfated batteries
  -  Force Mode
     Used to charge batteries below 1 volt

• Detects sulfation/acid stratification



• Repairs and reverses the damage
  done to your battery

• Extends the usable life

• Increases performance

• Integrated thermal sensor

• Monitors and adjusts the charging cycle
  based on fluctuations of ambient temperature

• Limits the chance of under-charging or over-charging

• Leaves a more accurate and fully charged battery

• Avoids under-charging in cold weather down to -4 F
  and avoids over-charging in hot weather up to 104 F.



• Comes with clamps built with needle-nose profiles



• Works with smaller terminal applications

• Detachable integrated eyelets to
  permanent mount to your battery

• Fits battery terminals of any shape and size

• Improved clamping range, clamping force,
  and higher conductivity


• Measurements:





Specifications:

• Input Voltage AC:
  120-240 VAC, 50-60Hz

• Working Voltage AC:
  120-240 VAC, 50-60Hz

• Output Power:
  75W Max

• Charging Voltage:
  Various

• Charging Current:
  5A (12V), 5A (6V)

• Low-Voltage Detection:
  1V (12V), 1V (6V)

• Back Current Drain:
  <0.5mA

• Ambient Temperature:
  -20�C to +40�C

• Type of Batteries:
  6V & 12V

• Battery Chemistries:
  Wet, Gel, MF, CA, EFB, AGM, Calcium, Lithium

• Battery Capacity:
  Up to 120Ah, Maintains All Battery Sizes

• Housing Protection:
  IP65

• Cooling:
  Natural Convection

• Dimensions (L x W x H):
  4.6" (117mm) x 2.9" (74mm) x 1.9" (48mm)

• Weight:
  1.5 Pounds (0.68kg)



Includes:

• Battery charger and maintainer with
  a 72" (182mm) cord that plugs into a standard outlet
  and a 56" (142mm) cord that plugs to the clamps




• Battery clamps and integrated eyelets
  with a 21" (55mm) cord





• Mounting bracket and strap







• (2) 8x1" self tapping screws
